Logistics automation

Flexible feeding methods

LAG provides a variety of feeding methods for raw materials to meet the demand of different production lines.

Feeding of tower-type material library

Provide the production with raw materials through single tower or double tower even more tower-type material library combinations and use space reasonably. You can get more manufacturing space.

Different specifications of smart material libraries can be selected in accordance with the metal plate thickness and size.

Feeding method of double row material library

Provide the logistics center for manufacturing with higher capacity, and withdraw materials from the material library directly in order to bring huge promotion of output.

Coil feeding method

LAG coiled material stamping automation system is utilized for feeding, and the CNC system controls the steel strip's feeding in the X-axis direction by controlling the movement of plunger chip installed on sliding car of stamping unit in the Y-axis direction. Such kind of composite punch (namely the coiled material punching production line) can guarantee the maximum production efficiency. In the meantime, such system owns the straightening function and can be compatible with multiple sub-modules.

Material transfer methods in production line

Direct transfer

Send to the next process through the ball bearing belt conveyor or belt driven by the motor

Three-axis stacking manipulator

Three-axis stacking manipulator takes materials from raw material library

Coordinate the vacuum chuck gripper system

Walking-type manipulator

Take materials through walking-type manipulator, conform to the production takt and connect the production link.

Coordinate the manipulator gripper. The gripper can be automatically replaced through the software system.

Processing of blanking and waste materials

Direct blanking

Achieve the direct blanking by driving the driving belt by the motor. Then the materials are taken away by the forklift or trolley.

Automatic stacking of manipulator

Manipulator automatically places the processed work piece at the designated position as per the preset program.

The sorting and stacking of small work piece are conducted to screen the small work pieces at the designated station by virtue of the visual identification system of manipulator.

Sorting of waste materials

The small-size waste materials can fall into the lower trolley by virtue of the turning plate-type mechanism on conveyor belt as per the size and volume of waste materials, then are taken away manually or by machine.

The large-size waste materials and frame-type waste materials are conveyed to the terminal pallet of production line and are taken away.

The laser cutting process can be preset in the processing process. The laser cuts the waste materials into small size which fall into the turning plate and are taken out of the production line.

Intelligent material library system

Configuration of smart material library

The material library system makes the manufacturing more orderly. The machine tools can connect with warehousing system through the transport vehicle. The transport vehicle can provide the raw materials for the machine tools or put the completed work pieces in the warehouse.

It will provide you with lots of advantages:

reasonable usage space, you can obtain maximum manufacturing space

efficient material assembly line, save lots of time and money for you

Regular inventory function makes you master the inventory condition at any time

Material library+ Software=Logistics Center

LAG material library and software solution are used. We can provide you with a logistics center used for manufacturing.

Smart Material Library Center can supply the material for all related machine tools, produce the semi-finished products /finished products for the intermediate storage, then place the supply materials/semi-finished products at the reasonable position within the specified time in combination with the generating process and plan to prepare the manufacturing step (such as bending) in the next step constantly, achieving the perfect material assembly line.

Besides, Logistics Center can ensure the safety in processing process of materials (the logistics wouldn't be damaged) and own lots of functions, such as research without spending time, automatic recognition of minimum distance, direct withdrawal of materials, etc.
